NC3MAHR

3 pole male XLR receptacle, grounding: ground contact connected to shell ground, but not to front panel and Pin 1, lateral right PCB mount

The ‘State of the Art’ receptacle. Round plastic body XLR PCB mount panel connector. These have the smallest size and highest packing density (23 mm between centres). New designed fork type contacts with hard gold plating and polished contact areas. UL recognized component.

FEATURES & BENEFITS

• Smallest XLR receptacles, highest packing density
• Plastic housing, steel latch lock
• Polished contact areas and hard gold plating
• Housing flammability UL94V-0
