| Max. Power Output |
50 Watts |
|
|
Amplifier |
Class D |
|
|
Sensitivity |
Typical: 90 dB | Maximum: 102 dB |
|
|
T.H.D. |
< 1% |
|
|
Frequency Response |
50 Hz ~ 18 kHz |
|
|
Speaker |
5 ” full-range, high efficiency |
|
|
Audio Inputs |
Wired: 6.3 mm (1/4 “) |
|
| Line-In: 3.5 mm (1/8 “) |
|
Bluetooth Connectivity |
Yes |
|
|
Audio Output |
3.5 mm (1/8 “) |
|
|
Alarm Siren |
Siren sound with fade-in mode |
|
|
Installation |
Microphone stand, table mounted, shoulder belt. |
|
|
Power Supply |
AC: External 100 ~ 240V AC switching power supply (Max. Power Consumption: 60 W) |
|
| DC & Battery:Built-in 14.8 V / 2.6 AH rechargeable lithium battery (MB-10 × 1) |
|
Charge Time |
4 hours (automatic charging management) |
|
|
Standby Time |
MA-100SB: > 12 hours |
|
| MA-100DB: > 10 hours |
|
Battery Indicator |
4-level indicator (25/50/75/100%) |
|
|
Color |
Black or white option |
|
|
Dimensions (W×H×D) |
135 × 144 × 240 mm / 5.3 × 5.6 × 9.4 “ |
|
|
Weight |
MA-100SB: Approx. 1.8 kg / 3.9 lbs (MB-10 battery included) |
|
| MA-100DB: Approx. 1.9 kg / 4.1 lbs (MB-10 battery included) |
|
Wireless System |
|
|
Receiver Channel |
MA-100SB: Single |
|
| MA-100DB: Dual |
|
Frequency Range |
UHF 480 ~ 934 MHz (country dependent) |
|
|
Bandwidth |
24 MHz |
|
|
Preset Channels |
16 |
|
|
Channel Set-up |
Scan & ACT sync |
|
|
Transmitter |
ACT-32H / ACT-32HC Handheld︱ACT-32T / ACT-32TC Bodypack |
|
|
Microphone |
MM-107 Wired Dynamic Microphone |
|
|
Antenna |
Built-in dual antennas |
|
|
Audio Player |
|
|
Built-in USB Port |
USB 2.0 |
|
|
USB Play & Record |
LCD displays track name, number, time, recording status. |
|
|
Operation |
On-board. USB remote control included. |
|
|
Patents & Approvals |
Patented. Telecom and safety regulations approved. |
|
|
Note |
Refer to actual product in the event of product description discrepancy. |
|
| Frequency range and maximum deviation comply with the regulations. |
