Chiayo

CHI-SDR8200M-5A

Chiayo – SDR8200M-5A – 100 Channel Receiver Module – UHF – Band 5A 520 – 526 MHz – True Diversity

$329.00 $254.98

Quantity

SDR8200M 100Ch True Div Uhf RX Module Chiayo

CH-SDR8200M-5A

SDR8200M factory preset user-selectable UHF frequencies

  • 5A: 520-526MHZ
  • 5B: 566-590MHZ
  • 6: 650-675MHZ



Receiving mode True diversity
Bandwidth 25 MHz
Preset frequencies 100
Channel sync 2-way (RX ⇔ TX)
Frequency response 50 Hz – 18 KHz
Peak deviation ± 40 KHz
Sensitivity S/N > 80 dBm at 10 dBμV
S/N ratio > 85 dB(A)
T.H.D. < 0.5% @ 1 KHz
Receiving antenna Built in
Modulation FM
Squelch Pilotone & Noise-cancelling dual-squelch circuit
Audio Output Adjustment Volume knob for adjustment of output volume
Power supply 12V DC
Dimensions (mm) 74 × 138 × 36
Weight (g) 102
SKU CHI-SDR8200M-5A Categories , , , ,
