Focus Port Pa Bt Only No Mod FOCUS-00PB Chiayo

FOCUS-00PB

Focus 505 50 watt portable PA with 6.5 inch speaker. Includes DPRB500M Digital rec/play, USB/Bluetooth module only,
no receiver modules. Lead acid batteries. Includes SB21 carrybag

Features

• High efficiency Class D amplifier produces 30W RMS audio output (maximum music output 50W)
• All-in-one! Easy to operate in both indoors and outdoors.
• Portable amp system eliminates all cables so you can take it anywhere!
• Speaker system: 6 ½“ full range.
• Voice priority.
• Audio inputs: Mic in, Aux in.
• Audio outputs: Aux out, External speaker.
• Individual volume control for Mic in, Aux in, Bass, Treble.
• Up to 2 diversity receiver modules with 100 selectable frequencies in each.
• Optional devices: receiver/transmitter/Bluetooth receiver/Digital music player with recorder.
• Tripod stand mountable with ST-40/Wall mountable with SR-40.
• Optional carrying bag (SB-21).
• Portable amplifier: PA-505R
• Focus speaker: SP-505

Specifications

• Max power output    50W, 4Ω Load (class-D)
• Speaker system    6 ½” full range
• Frequency response    50Hz-20KHz±3dB
• T.H.D.    < 0.5%
• Audio input    MIC in (Ø6.3mm),
• AUX in (Ø6.3mm)
• Audio output    AUX out (Ø6.3mm)
• External speaker    4~8Ω (Ø6.3mm)
• Power supply    100-240V AC, 15V DC / 3.75A
• Battery    Lead-acid (12V / 2.9Ah) x1
• Operating time    5-6 hours in music, 10-12 hours in speech
• Charging time    about 4 hours
• Dimensions (mm)    220 x 215 x 313
• Weight (kg)    4.8
