• Features 4 x analogue audio inputs that are converted to a Dante® compatible signal
• Features conversion of 4 x Dante® signals to analogue audio outputs
• Analogue audio inputs support both balanced and unbalanced audio + MIC line level signals
• MIC line level supports 48V phantom power
• Supports 44.1, 48 & 96kHz sample rates @ 24-bit
• Configurable Dante® device latency (supports 1, 2 or 5ms configurable using Dante® Controller)
• Independent input gain settings per channel
• Supports AES67 RTP audio transport

• Audio Input Connectors: 12-pin Phoenix connector (4ch balanced / unbalanced analogue audio / MIC)
• Audio Output Connectors: 2 x RJ45, female (1Gb Dante® network), 12-pin Phoenix connector (4ch balanced / unbalanced analogue audio / MIC)
• Casing Dimensions (W x D x H): 215mm x 145mm x 44mm without feet
• Operating Temperature: 32°F to 104°F (-5°C to +55°C)
• Storage Temperature: -4°F to 140°F (-25°C to +70°C)
• Power Supply: 12V/1A DC
