SERVER-IO AVB

Configurable I/O DSP with up to 48 channels of I/O, 1 DSP-2 card (two additional DSP-2 cards can be added), and one AVB-1 network card.

Key Features

• Configured with one AVB-1 network card
• Supports up to three DSP-2 cards
• Supports up to 12 I/O cards with a maximum of 48 channels of analog audio
• Up to 420×420 channels of digital I/O over AVB
• Supports optional 32×32 CobraNet audio networking
• Supports optional 64×64 Dante audio networking
• System configuration and control via Ethernet or serial connection
• Front panel OLED display for device and system information
• SpeechSense and AmbientSense processing algorithms
• Signal processing via intuitive software allows configuration and control for signal routing and mixing, equalization, filtering, dynamics, delay and much more
• Extensive input, output and logic expansion devices supported as part of the Tesira digital audio networking platform
• Rack mountable (3RU)

Overview
