Electrical

24 VDC, 70 Watt max. on 2.1mm barrel connector

24 VDC Power supply (100-240 VAC) included

Ethernet

10/100Mbps auto,

RJ-45 connector with integrated Link/Activity LED

Protocols: TCP/IP, UDP, RTP, SIP, DHCP,

Analog Output

2 x 25 W (RMS @ 8 Ohm) speaker outputs,

3.5 mm (1/8 inch) headphone jack,

S/P DIF out (optical),

Output level software controllable

Frequency response (-3 dB) 19 Hz .. 20 kHz *

Dynamic range 94 dB

SNR/THD -94 dB, <0.05%)

Audio formats

MP3 CBR/VBR, up to 320 kbps, 8..48 kHz sample freq.

AAC-HE (AAC, AAC plus, AAC plus V2)

WMA (up to version 9),

Ogg Vorbis

PCM linear 16bit @8, 16, 22.05, 24, 32, 44.1, 48 kHz

G.711, uLaw, aLaw (sample rates same as PCM)

RS-232 Interface

300..230‘400 Baud asynchronous,

for serial tunneling or local control,

12 VDC supply output for external devices

(100 mA max.)

IR Interface

Built-in IR receiver, IR remote control included,

Optional external IR receiver via serial port (IR Kit)

Mechanical

Aluminum case, 460g

rack and wall mountable using accessories

Dimensions (W x H x D)

108 x 38 x 125 mm (4.25 x 1.5 x 4.92 inch)

Model comparison

Model 200 Speaker output 2 x 25 Watt on 8 Ohm, Memory USB

Model 205 Speaker output 2 x 25 Watt on 8 Ohm, Memory MicroSD, Line in

MTBF

According MIL217F at 25°C

Exstreamer 200 min. 460 000h

Exstreamer 205 min. 410 000h

* depends on used codec, best results @48kHz PCM
