Amplifiers

AUS-HS4120P

Australian Monitor – HS4120P Amplifier – Power – 4 x 120 Watt 100 Volt

$2,325.00 RRP Inc GST

Quantity

Australian Monitor – HS4120P

4 x 120W Power Amplifier
USB/RS232 Control w mini DSP

The HSP series is Australian Monitor’s next generation of controllable Class D power amplifiers, delivering high quality audio reinforcement with the power you need in the following options -Single channel 120W or 250W, Dual channel 120W or 250W and Quad channel 120W or 250W.

Our new power amplifiers are fully featured, including an efficient Class D amplifier, USB and RS232 control and a mini DSP featuring volume control, mute, compressor/limiter, filter and input channel selection.

The HSP series power amplifiers give the AV contractor a reliable amplifier for applications that are price sensitive yet still require high quality commercial sound reinforcement and control.

• 4 x 120W power amplifier
• 4 ohm, 70V and 100V output options
• Class D topology
• Programmable via PC UI application
• USB and RS232 control
• Mini DSP – Volume controls, input / output routing, high and low pass filtering, compressor / limiter, pink noise / sine wave generator, muting and inversion
• Mute control via contact
• Standby control via contact
• Fault status via contact

Output Power per Channel 120W Frequency Response 100Hz – 16kHz
Output Channels 4 THD+N < 0.2% (-3dB)
Output Mode 4 Ohm-70V-100V Signal to Noise Ratio > 92dB
Input Voltage 100-240Vac 50-60Hz Input Sensitivity 1Vrms
Mounting 2RU Cooling Fan-assisted
Warranty 5 years
Product Dimensions
(W x D x H)
483mm x 389mm x 89mm Shipping Dimensions
(W x D x H)
546mm x 491mm x 197mm
Net Weight 14.0 Kg Shipping Weight 15.6 Kg



____________________________________

HS Series Family Overview

HS4120P Brochure

HS4120P Manual

HSP Control Software Installer V1.6.0 (WIN)

HSP Control Software Installer V1.4.0 (WIN)

HSP Control Software Installer V1.2.0 (WIN)

HSP Control Software Installer V1.1.0 (WIN)

ALMA Interface Protocol Usage and Examples

ALMA Interface Protocol Specification
