Aiphone – IX-SSA-RA – Entry Station Audio – Emergency
$1,493.40 RRP Inc GST
SIP Compatible IP Emergency Station
ADA Compliant with a Single Emergency Call Button
Need this station with UL Certification? Be sure your model has a UL sticker or contact Aiphone for more details.
The Aiphone AI-IX-SSA-RA is a flush mount, weather resistant (IP65) and IP addressable video call station. This station has a single emergency call button and a placard with raised lettering and Braille signage. The call button can call up to 20 different stations and the emergency button can be programmed to call up to 20 different stations.
Power Source
PoE (IEEE 802.3af class 0) or 24V DC (PS-2420UL)
Power Draw
3.36 Watts @ 48V DC
Audio Codec
G.711 (μ-law, A law), G.722
Protocols
IPv4, IPv6, TCP, UDP, SIP, HTTP, HTTPS, RTSP, RTP, RTCP, IGMP, MLD, SMTP, FTP, DHCP, NTP, DNS
Port Security
IEEE 802.1X
Operating Temp
-40° – 140°F (-40° – 60°C)
Ingress Protection
IP65
Impact Protection
IK08
Dimensions
10-7⁄16″ H x 5-⅞” W
Mounting
Flush mounted with included back box, or surface mount with the SBX-IDVFRA Stainless Steel surface mount box. Also compatible with the WB-CA, WB-HA, WB-CE, and WB-HE Emergency wall boxes or modular towers.
